Cat 3406C Diesel Engine

15174146

Cat 3406C Diesel Engine

Caterpillar

Units of measurement :

Metric

Imperial

Maximum Power

347 kW

465 hp

Maximum Torque

2172 Nm @ 1350 rpm

1602 lb-ft @ 1350 rpm

Emissions

Non-Certified

Availability

Purchase Rental Used

The Cat 3406C Industrial Diesel Engine is offered in ratings ranging from 298-347 bkW (400-465 bhp) @ 1800-2100 rpm and is available for global non-regulated areas. Industries and applications powered by 3406C engines include

Features

Specifications

Reliable, Quiet and Durable Power

Fuel Efficiency

Broad Application Range

Quality

World-class Product Support Offered Through Global Cat Dealer Network

World-class manufacturing capability and processes coupled with proven core engine designs assure reliability, quiet operation, and many hours of productive life.

Fuel consumption optimized to match operating cycles of a wide range of equipment and applications while maintaining low operating costs.

Industry leading range of factory configurable ratings and options for agricultural, material handling, construction, mining, aircraft ground support, and other industrial applications.

Every Cat engine is manufactured to stringent quality standards in order to assure customer satisfaction.

Scheduled maintenance, including SOS^SM sample
Customer Support Agreements (CSA)
Caterpillar Extended Service Coverage (ESC)
Superior dealer service network
Extended dealer service network through the Cat Industrial Service Distributor (ISD) program

Scheduled maintenance, including SOS^SM sample
Customer Support Agreements (CSA)
Caterpillar Extended Service Coverage (ESC)
Superior dealer service network
Extended dealer service network through the Cat Industrial Service Distributor (ISD) program

Power Rating

Maximum Power	347 kW	465 hp
Maximum Torque	2172 Nm @ 1350 rpm	1602 lb-ft @ 1350 rpm
Rated Speed	1800-2100 rpm
Minimum Power	280 kW	375 hp

Emission Standards

Emissions

Non-Certified

Engine Dimensions - Approximate

Length	1660 mm	65.4 in
Width	906 mm	35.7 in
Height	1335 mm	52.6 in
Weight - Net Dry - Basic Operating Engine Without Optional Attachments	1300 kg	2866 lb

General

Engine Configuration	Inline 6, 4-Stroke-Cycle Diesel
Bore	137 mm	5.4 in
Stroke	165 mm	6.5 in
Displacement	14.6 l	893.4 in³
Compression Ratio	14.5:1
Aspiration	Turbocharged Aftercooled
Rotation from Flywheel End	Counterclockwise
Aftertreatment	-
