C175-16 Generator Set

Units of measurement :

Metric

Imperial

Standby Rating

3100(no fan)/3000 kVA

Prime Power Rating

2825(no fan)/2725 kVA

Emissions/Fuel Strategy

Low Fuel, Low Emissions

Availability

Purchase Rental Used

Caterpillar is leading the power generation marketplace with Power Solutions engineered to deliver unmatched flexibility, expandability, reliability, and cost-effectiveness.

Over 20,000,000 Operating hours

at Global locations

Over 3000 units

In the field

Highest Rated Tier 4 Product

Available on the market

Cat Generator Set Package

Cat Diesel Engine

SR5 Alternator

Cat ECS Control Panel

Cooling System

Certifications

One Safe Source

Worldwide Product Support

Cat generator set packages have been fully prototype tested
Accepts 100% block load in one step and meets NFPA 110 loading requirements
Conform to ISO 8528-5 steady state and transient response requirements

Electric Power Rating Guide.pdf C175-16, 50 Hz, 3000 kVA Standby_MC, 2725 kVA Prime, 2500 kVA Cont., Low Fuel Consumption _ Low Emissions (with fan) Spec Sheet.pdf C175-16, 50 Hz, 3100 kVA Standby_MC, 2825 kVA Prime, 2600 kVA Cont., Low Fuel Consumption _ Low Emissions (without fan) Spec Sheet.pdf C175-16, 50 Hz, 2725 kVA, Prime-DCP, Low Fuel Consumption (with fan) Spec Sheet.pdf C175-16, 50 Hz, 2825 kVA, Prime-DCP, Low Fuel Consumption (without fan) Spec Sheet.pdf

Generator Set Specifications

Standby Rating	3100(no fan)/3000 kVA
Prime Power Rating	2825(no fan)/2725 kVA
Emissions/Fuel Strategy	Low Fuel, Low Emissions
Voltage	380 to 11000 Volts
Frequency	50 Hz
Speed	1500 rpm
Duty Cycle	Standby, Mission Critical, Prime, Continuous
Maximum Rating	3100 kVA
Minimum Rating	2500 kVA

Engine Model	C175-16 SCAC, V-16, 4-Stroke Water-Cooled Diesel
Bore	175 mm	6.89 in
Stroke	220 mm	8.66 in
Displacement	84.7 l	5166.88 in³
Compression Ratio	16.7:1
Aspiration	Turbo Aftercooled
Fuel System	Common Rail
Governor Type	ADEM� A4

Length - Minimum	6137 mm	241.6 in
Length - Maximum	7900 mm	311 in
Width - Minimum	2110 mm	83 in
Width - Maximum	2786 mm	108.5 in
Height - Minimum	2211 mm	87 in
Height - Maximum	3307 mm	130.2 in
Dry Weight - Genset (minimum)	19391 kg	42750 lb
Dry Weight - Genset (maximum)	23020 kg	50750 lb
